Our Manufacturing Capabilities
50,000m² facility. 600+ employees. 80+ engineers. Equipment less than 3 years old. These aren't aspirations — these are our specs today.
Board Specifications
Layers1–48 (up to 64 for special projects)
Board Thickness0.1mm – 8.0mm
Max Board Size800mm × 800mm
Min Board Size3mm × 3mm
PanelizationV-scoring, Tab Routing, Punch, Depanel
Bow & Twist≤ 0.5% (tighter on request)
Circuit Features
Min Trace/Space1.5/1.5mil (0.038mm) — top tier
Min Drill (Mechanical)0.10mm
Min Drill (Laser)0.075mm
Min Annular Ring0.04mm
Hole Plating Thickness≥ 25μm
Impedance Tolerance±2% (controlled) / ±3% (standard)
Surface Finishes
HASL (Lead-Free)✓ Available
ENIG (Electroless Nickel Immersion Gold)✓ Available
ENEPIG✓ Available
OSP (Organic Solderability Preservative)✓ Available
Immersion Silver✓ Available
Immersion Tin✓ Available
Hard Gold Plating✓ Available
Carbon Ink✓ Available
Materials (Rigid FR-4)
Standard FR-4Tg130 – Tg140 (KB, Nanya, Shengyi)
High Tg FR-4Tg170 – Tg180 (lead-free compatible)
Isola370HR, 410HR, I-Tera MT40
Megtron 6High-speed, low-loss
Rogers (Hybrid Stack)RO4003, RO4350B (mixed with FR-4)
Halogen-FreeAvailable (Phosphorus/Nitrogen based)
Solder Mask & Silkscreen
Solder Mask ColorsGreen, Red, Blue, Yellow, Black, White, Purple, Matte colors
Silkscreen ColorsWhite, Black, Yellow
Solder Mask TypeLiquid Photo-Imageable (LPI), Dry Film
Peelable Solder Mask✓ Available
Quality & Testing
Electrical Testing100% Flying Probe / fixture test
AOI Inspection100% automated optical inspection
X-Ray Inspection✓ Available (BGA, QFN)
IPC ClassClass 2 standard, Class 3 available
UL CertificationUL 94V-0
ISO CertificationsISO 9001:2015, ISO 14001:2015, IATF 16949
PCB Assembly Capabilities
Full turnkey and consignment assembly services
SMT Components01005 to 80mm × 80mm QFP/BGA
Through-HoleManual, wave, and selective soldering
BGA/QFN PitchDown to 0.25mm
Chip Placement Accuracy±0.020mm (±20μm)
Placement Speed120,000 CPH per line
Mixed TechnologySMT + THT + selective solder on same board
Lead-Free Process✓ RoHS / REACH compliant
ICT / Functional Test✓ Custom fixture design available
Conformal Coating✓ Spray, dip, brush — acrylic, silicone, urethane
BOM Sourcing✓ Turnkey — we source all components
Certifications
Our quality management system meets international standards
ISO 9001:2015
Quality Management
ISO 14001:2015
Environmental Management
IATF 16949
Automotive Quality
UL Certified
UL 94V-0 Flammability
Have Specific Requirements?
Our engineers can review your design and recommend the best manufacturing approach.
